Dissolved Oxygen Meter

Get a Price/Quote

Dissolved Oxygen Meter Specification

Humidity %
85% RH

Measurement Range
0.0 - 20.0 mg/L

Resolution
0.1 mg/L

Sensor Type
Polarographic oxygen probe

Connectivity Type
Wired probe

Equipment Type
Portable Dissolved Oxygen Meter

Temperature Range
0C - 50C

Material
ABS plastic body

Power Supply
4 x 1.5V AA batteries

Power Consumption
~150 mW

Accuracy
0.4 mg/L or 1% FS

Display Type
Large digital LCD

Range
0.0 - 20.0 mg/L

Operating Temperature
0°C to 50°C

Auto Power Off
Yes

Protection Class
IP54

Data Hold Function
Yes

Calibration
Manual calibration

Storage Case
Standard carrying case included

Probe Cable Length
About 1 meter

Dimensions
Approx. 185 x 40 x 35 mm

Weight
Approx. 290 g

Dissolved Oxygen Meter Trade Information

Payment Terms
Cash on Delivery (COD), Paypal, Letter of Credit (L/C), Western Union, Letter of Credit at Sight (Sight L/C), Delivery Point (DP), Cash Against Delivery (CAD), Telegraphic Transfer (T/T), Days after Acceptance (DA), Cash in Advance (CID), Cheque, Cash Advance (CA)

Delivery Time
as per requirement Days

Sample Available
Yes

Main Domestic Market
All India

About Dissolved Oxygen Meter

Dissolved Oxygen Meter

Lutron Make,

Model : DO-5510,

Features:

Pocket size
With m-Pcircuit
LCD with annunciator.
Max., Min, Memory recall button.
DO, Oxygen in air, Temperature, ATC, Auto calibration.

Precise Measurement in Any Environment

Engineered for reliable dissolved oxygen assessments, this meter functions across a wide range of temperatures and humidities, making it ideal for field and lab use. Its polarographic oxygen sensor and robust ABS plastic housing ensure lasting performance, while its compact form factor and protective IP54 rating guarantee ease of transport and operation even in challenging conditions.

User-Friendly Operations and Features

With manual calibration, a large LCD display, and data hold capability, this dissolved oxygen meter simplifies testing procedures. The auto power-off feature conserves battery life, and the devices power requirements are minimal. Supplied with a standard carrying case, the meter is both portable and convenient for users ranging from researchers to water quality technicians.

FAQs of Dissolved Oxygen Meter:

Q: How do I calibrate the Portable Dissolved Oxygen Meter?

A: Manual calibration is performed by following the manufacturers instructions, adjusting the meter in known calibration solutions before measurements. This ensures accuracy and reliability of the readings in various water samples.

Q: What is the recommended operating temperature range for this device?

A: The meter operates effectively within a temperature range of 0C to 50C, making it suitable for most laboratory and environmental conditions.

Q: Where can I use the Dissolved Oxygen Meter?

A: This portable meter is suitable for fieldwork, laboratory experiments, aquaculture, wastewater monitoring, and environmental surveys in India, thanks to its robust build and protective carrying case.

Q: What is the process for measuring dissolved oxygen with this device?

A: To measure dissolved oxygen, connect the polarographic oxygen probe, calibrate the meter, submerge the probe in the sample, and read the oxygen concentration on the large digital LCD display. Use the data hold feature if needed to retain measurements.

Q: What are the benefits of the data hold and auto power-off functions?

A: The data hold function allows users to freeze the current measurement on the display for easy recording, while auto power-off conserves battery life during periods of inactivity, enhancing efficiency.

Q: When should the batteries be replaced in the Dissolved Oxygen Meter?

A: Replace the four AA batteries when the display dims or the unit fails to power on. Using fresh batteries ensures consistent operation and accurate results.

Q: What protection level does the Dissolved Oxygen Meter offer?

A: The meter has an IP54 protection class, which safeguards it against limited dust ingress and water splashes, providing durability for outdoor and industrial applications.
